Every rock on Earth is made of up a unique combination of chemical elements, and lavas/tephra formed during Hawaiian eruptions are no exception. What is the geochemistry of Kilauea’s newest tephra — and how can it help us understand the processes driving the ongoing eruption?
New eruptions at Kilauea provide a glimpse into what is happening inside the volcano and its magma reservoirs. The recent summit eruption, which began on the night of Dec. 20, 2020, allows us to “see inside” the volcano once more and learn more about where the magma supplying the eruption is coming from.
To think about where magma is stored and how it moves prior to eruption, geologists can measure the chemistry of erupted materials — including quenched lava (glass), minerals, and dissolved gases or gas bubbles. The chemistry can tell us a lot about how hot the magma was at depth, how long it sat inside the volcano prior to arriving at the surface, and how different magmas (old vs. fresh, cooler vs. hotter) might have mixed together before erupting.
So what does Kilauea’s youngest tephra, which are particles of the magma thrown out of the vent that fall through the air, tell us about this eruption? A simple way to start investigating is to look at how much of the element magnesium (Mg) they contain.
We use Mg (expressed as MgO, or magnesium oxide) measured in glass (for example, quenched lava) to determine how hot a magma is, which indicates how recently it arrived at Kilauea from its source deep below the Island of Hawaii. Higher MgO contents indicate “fresh” hot magmas entering Kilauea’s shallow reservoir shortly prior to eruption, whereas lower MgO contents reflect “older” colder magmas that have been stored within the volcano for longer periods of time.
Shortly after the first tephra erupted on the 20 and 21 of December 2020, the USGS Hawaiian Volcano Observatory worked with the electron microprobe lab housed at the University of Hawaii at Manoa to measure MgO in the new quenched lavas. The new tephras have glass MgO contents of approximately 7 weight percent, which is very similar to the composition of Kilauea’s previous lava lake in 2018. This indicates that the current eruption did not begin with “fresh” hot magma entering Kilauea’s shallow summit reservoir. Instead, the eruption is likely drawing magma from the same shallow source that fed the 2008–2018 lava lake.
Olivine crystals (the bright green mineral commonly found in Hawaiian lavas) also have a lot of Mg. In olivine the abundance of Mg is expressed as the forsterite content (Fo) —which is a ratio of how much Mg there is compared to the iron (Fe) content [Mg/(Mg+Fe)x100]. Similar to the glasses, higher Mg in olivine (for example, higher Fo) means that the crystals grew from hotter, fresher magmas. If the olivine Fo content is low, it tells us that the crystals grew in a cooler magma. The first olivine crystals to grow in the freshest, hottest magmas rising beneath Kilauea typically have Fo contents of 88–90.
Kilauea’s newest olivine crystals, which are typically about 0.5 mm (0.02 inches) in diameter, have relatively low Fo values of 82. This suggests that the crystals grew in relatively cool magmas stored at shallow depths (up to a few km or less than 2 miles below the ground surface) at Kilauea. The crystals are also chemically homogeneous, meaning that there are no changes in Fo content from the middle to the rim. This tells us that mixing between hotter (higher MgO) and colder (lower MgO) magmas has not occurred recently at Kilauea’s summit.
Together, the low-MgO glasses and homogeneous, low-Fo olivine indicate that hot, fresh magma has not been erupted. Instead, these compositions tell us that older, “cooler” magma — possibly the left over magma from 2018 — is erupting now at Kilauea’s summit. HVO scientists are continuing to monitor the chemistry of newly erupted materials, and changes in glass MgO or olivine Fo could help us understand future changes in the eruption.
Volcano activity updates
Kilauea Volcano is erupting. Its USGS Volcano Alert level is at WATCH (https://www.usgs.gov/natural-hazards/volcano-hazards/about-alert-levels). Kilauea updates are issued daily.
Lava activity is confined to Halema‘uma‘u with lava erupting from a vent on the northwest side of the crater. This morning, Jan. 21, the lava lake was about 202 m (663 ft) deep and remains stagnant over its eastern half. Sulfur dioxide emission rate measurements made on Jan. 16 were about 2,500 t/d, below the range of emission rates from the pre-2018 lava lake. Summit tiltmeters are on a deflationary trend. Seismicity remains elevated but stable, with steady elevated tremor and a few minor earthquakes. For the most current information on the eruption, see https://www.usgs.gov/volcanoes/Kilauea/current-eruption.
Mauna Loa is not erupting and remains at Volcano Alert Level ADVISORY. This alert level does not mean that an eruption is imminent or that progression to eruption from current level of unrest is certain. Mauna Loa updates are issued weekly.
This past week, about 56 small-magnitude earthquakes were recorded beneath the upper-elevations of Mauna Loa; most of these occurred at depths of less than 8 kilometers (about 5 miles). The largest recorded earthquake was a M2.9, just east of the summit caldera, on Jan. 18, at 10:26 p.m. HST. Global Positioning System measurements show continued slow summit inflation, consistent with magma supply to the volcano’s shallow storage system. Gas concentrations and fumarole temperatures at both the summit and Sulphur Cone on the Southwest Rift Zone remain stable. Webcam views have revealed no changes to the landscape over the past week.
There were 10 events with 3 or more felt reports in the Hawaiian Islands during the past week: a M2.7 earthquake 10 km (6 mi) E of Pahala at 30 km (19 mi) depth on Jan. 19 at 9:45 p.m. HST, a M2.4 earthquake 11 km (6 mi) NNE of Puako at 15 km (9 mi) depth on Jan. 19 at 7:29 a.m HST, a M3.2 earthquake 8 km (4 mi) N of Naalehu at 0 km (0 mi) depth on Jan. 18 at 10:55 p.m. HST, a M2.7 earthquake 20 km (12 mi) SW of Pa‘auilo at 22 km (13 mi) depth on Jan. 16 at 11:58 p.m. HST, a M2.5 earthquake 7 km (4 mi) SE of Leilani Estates at 1 km (1 mi) depth on Jan. 15 at 9:03 p.m. HST, a M1.7 earthquake 11 km (6 mi) ESE of Waikoloa at -1 km (-1 mi) depth on Jan. 15 at 8:26 a.m. HST, a M2.2 earthquake 9 km (5 mi) ENE of Pahala at 31 km (19 mi) depth on Jan. 14 at 7:20 p.m. HST, a M1.8 earthquake 8 km (4 mi) ENE of Pahala at 32 km (20 mi) depth on Jan. 14 at 6:42 p.m. HST, a M1.8 earthquake 6 km (3 mi) ENE of Pahala at 33 km (20 mi) depth on Jan. 14 at 6:28 p.m. HST, and a M4.0 earthquake 8 km (4 mi) ENE of Pahala at 34 km (21 mi) depth on Jan. 14 at 6:15 p.m. HST.
HVO continues to closely monitor both Kilauea’s ongoing eruption and Mauna Loa for any signs of increased activity.
