The limited collapse of the inner part of Kilauea Volcano’s caldera this summer fell well short of the larger summitwide collapses that occurred in the past.
How many such limited collapses can we recognize at Kilauea before written records were kept?
The answer is none.
Yes, none.
Without written descriptions, we could not identify past small-scale caldera collapses. The reason is that such collapses are confined to the inner part of the caldera itself, exactly where later eruptions and the next collapse take place.
The eruptions partly or completely fill the small collapse depression, and the next small collapse overprints the preceding one, like walking on someone else’s footsteps. We might get a geologic hint of repeated small collapses under favorable circumstances, but usually we are out of luck.
The much larger summitwide collapses, however, can be identified with careful research. Such collapses are probably less frequent than the limited collapses.
Between the summitwide collapses, there is time for, and good reason to expect, intervening explosive eruptions. These eruptions — powered by magmatic gas, steam or both — deposit ash and coarser debris outside the caldera, creating deposits that form markers helping to distinguish one summitwide collapse from another.
Putting together the evidence for such events is complicated, time-consuming, field-oriented research, but it paid dividends at Kilauea by recognizing large-scale cyclic behavior of the volcano during the past 2,500 years.
Among other things, we learned that each summitwide caldera collapse was followed by centuries during which the supply rate of magma to the ground surface was apparently low — only several percent of that for the past 200 years. As a result, only a few lava flows erupted from one of the rift zones outside the caldera.
Within the caldera, however, many explosive eruptions took place. Lava could have erupted in the caldera, but never with sufficient volume to fill the caldera and spill out to form surface flows. Eventually the supply rate increased, the caldera filled and lava flows erupted along the rift zones. The volcano has been doing this for the past 200 years.
The previous two summitwide caldera collapses occurred about 2,200 and 500 years ago, respectively. Each of these collapses was immediately preceded by the development of a very large flow field on the flank of Kilauea.
These two flow fields, the Kipuka Nene (2,200 years ago) and the Aila‘au (mid-15th century), are the largest that we know about on Kilauea in the past 2,500 years — the period of time for which we have good evidence. The eruption that formed the Aila‘au flow field lasted about 60 years; the eruption that formed the Kipuka Nene flow field probably lasted several decades.
What could be the reason that eruption of a vast flow field preceded a large caldera collapse?
There are two end-member possibilities. One is that rapid melting of rock in the mantle came to an end, so there was little magma coming up the pipe to replenish magma erupted in a large flow field. The other is that magma continued to ascend but was hijacked before reaching the ground surface, going somewhere else in or below Kilauea.
What about the large Pu‘u ‘O‘o flow field? That eruption lasted just more than 35 years and accumulated a volume equivalent to that of the Kipuka Nene flow field. That makes Pu‘u ‘O‘o either the second or third largest flow field known in the past 2,500 years on Kilauea.
Since each of the other two large flow fields immediately preceded a summitwide caldera collapse, is the Pu‘u ‘O‘o flow field sending a message? Will this summer’s small summit collapse eventually resume and ultimately engulf the entire summit?
The geologic evidence is insufficient to tell us how long it took for past large collapses to fully develop. Such collapses could have happened in only a few weeks or could have been spread throughout years to several decades.
In this light, this summer’s collapse could be all that will happen — or it could be the start of a longer period of repeated collapses that finally involve the entire summit. We simply can’t tell at this stage.
It will probably take decades before we know if the size of the Pu‘u ‘O‘o flow field was a harbinger of major collapse or only a red herring.
Volcano activity updates
At Kilauea’s lower East Rift Zone, no incandescence has been visible within the fissure 8 cone since Sept. 15. At the summit of the volcano, seismicity and ground deformation remain low.
Hazardous conditions still exist at the LERZ and summit. Residents in the lower Puna District and Kilauea summit areas should stay informed and heed Hawaii County Civil Defense closures, warnings and messages (http://www.hawaiicounty.gov/active-alerts).
No collapses at Pu‘u ‘O‘o have been observed since last weekend.
The combined sulfur dioxide emission rates at Kilauea’s summit, Pu‘u ‘O‘o and the lower East Rift Zone remain at less than 1,000 tonnes per day — lower than at any time since late 2007.
The USGS Volcano Alert level for Mauna Loa remains at Normal (https://volcanoes.usgs.gov/vhp/about_alerts.html).
HVO continues to closely monitor Kilauea and Mauna Loa and will report any significant changes on either volcano. Daily Kilauea updates are posted at https://volcanoes.usgs.gov/volcanoes/kilauea/status.html. Monthly Mauna Loa updates are posted at https://volcanoes.usgs.gov/volcanoes/mauna_loa/status.html.
One earthquake with three or more felt reports occurred in the Hawaiian Islands this past week: a magnitude-3.7 quake 48 km (30 mi) south of Lanai City at 8 km (5 mi) depth at 12:55 a.m. Sept. 15. Small aftershocks from the May 4 magnitude-6.9 earthquake are still being generated on faults located on Kilauea’s south flank.
Visit HVO’s website (https://volcanoes.usgs.gov/hvo) for past Volcano Watch articles, Kilauea and Mauna updates, volcano photos, maps, recent earthquake info, and more. Call 808-967-8862 for a Kilauea summary update. Email questions to askHVO@usgs.gov.
Volcano Watch (https://volcanoes.usgs.gov/hvo/hvo_volcano_watch.html) is a weekly article and activity update written by U.S. Geological Survey Hawaiian Volcano Observatory scientists and affiliates.
